Smart Speed Governor/Limiter

Governors are used to limit the top speed for vehicles, and for some classes of vehicle such devices are a legal requirement. They can more generally be used to limit the rotational speed of the internal combustion engine or protect the engine from damage due to excessive rotational speed. There are different types of speed governor available in the market including Electronic Fuel type speed governor, Motor controlled speed governor, Fly-by-wire speed governor and Pneumatic-type speed governor. All have different type of operation to control speed of vehicle and lock at the desired speed.

Electronic & Fuel type speed governor – A servo motor is linked to the throttle and controlled by an electronic device that senses engine speed by counting electrical pulses emitted by the ignition system or a magnetic pickup. The frequency of these pulses varies directly with engine speed, allowing the control module to apply a proportional voltage to the servo to regulate engine speed. Due to their sensitivity and rapid response to speed changes, electronic governors are often fitted to engine-driven generators designed to power computer hardware, as the generator's output frequency must be held within narrow limits to avoid malfunction.

In Fuel type speed governor, we control fuel flow from fuel tank to engine to control and lock vehicle at desired speed.

Micro-controller based design.

The product does not reduce fuel flow to engine and hence ensures full power to it.

Ease of installation.

Zero maintenance required.

Helps improve fuel economy by locking a vehicle at desired speed.

Increases engine life and reduces operating and maintenance costs.

Fly-By-Wire (features data logging with timestamp and overspeed alarm) This type of governor directly communicates with vehicle ECU (Electronic Control Unit). It senses engine speed by counting electrical pulses emitted by the ignition system or a magnetic pickup. The frequency of these pulses varies directly with engine speed. When vehicle reaches at desired speed, governor starts controlling speed by communicating.

Pneumatic (features data logging with timestamp and overspeed alarm) The governor mechanism detects air flow from the flywheel blower used to cool an air-cooled engine. The typical design includes an air vane mounted inside the engine's blower housing and linked to the carburettor’s throttle shaft. A spring pulls the throttle open and, as the engine gains speed, increased air flow from the blower forces the vane back against the spring, partially closing the throttle. Eventually a point of equilibrium will be reached and the engine will run at a relatively constant speed.

Includes feature of electronic speed governor - - It has all the features of traditional electronic speed governor with addition of below features.

Advanced Microcontroller based Design – ARM-Core M3 MCU based design.

Data Logging This governor not only limits speed but also save speed records with data-time stamp. This will give user access to monitor and check at what speed vehicle was running at what day and time.

Save and Retrieve Parameter & Data via USB User can save parameter configuration and retrieve data from speed governor directly by plugging flash/pen drive to speed governor.

Comes with Windows Application - This governor comes with windows application which enables user to generate speed graphs and reports in pdf.

Monitor Driver Behaviour - User can monitor driving behaviour of driver using generated reports.

Built-in Overspeed Alarm System - It also has alarm system which will raise when vehicle is about to reach its lock speed/ top speed at which vehicle is calibrated to run.

Easy Embedded Solutions is a reputed design house in Delhi, India. We have inhouse design facility and dedicated team.

We have variety of speed governors starting from traditional electronic speed governor to High-End Pneumatic and Fly-By-Wire type speed governors.

According to the need, size and scale of the industry we introduced the robust speed governors best suited for the automotive industry.

We offer High performance speed governors that are suitable for any type of working atmosphere.

Commercial Vehicles

School buses

Other areas of Driver driven vehicles

For Detailed technical specification, please contact at official e-mail or listed phone number. Click Here
